CZ purlin roll forming machine
5.5KW Hydraulic Cutting CZ Metal Steel Frame Purlin Roll Forming Machine
This C/Z Quick Interchangeable Roll Forming Machine adopts a special structure. The rollers for C&Z are changed very quickly without dismantle any parts . One machine can produce all specifications of C/Z/U purlins . Crimples are optional to increase rigidity of purlins. The width of the purlins can be automatically adjusted by PLC. If you need more economy then can be handle wheel adjusting as well. This machine we adopt Post-cutting and punching system, only need one cutting to make more size, the cutting blades can move up and down, left and right to save time to change blades.
|
C/Z Quick Interchangeable Machine |
|||
|
No |
Item |
Specification |
Optional |
|
1 |
Suitable material |
Type:Galvanized Coil, PPGI, Carbon steel Coil |
|
|
Thickness(mm):1.5-3.0 |
|||
|
Yield strength: 250 - 550MPa |
|||
|
Tensil stress( Mpa):G350Mpa-G550Mpa |
|||
|
2 |
Nominal forming speed(m/min) |
10-15 |
Or according to your requirement |
|
3 |
Forming station |
18 |
|
|
4 |
Decoiler |
Manual decoiler |
Hydraulic decoiler or double head decoiler |
|
5 |
Main machine motor |
China famous Brand |
Siemens |
|
6 |
PLC brand |
Panasonic |
Siemens |
|
7 |
Inverter brand |
Yaskawa |
|
|
8 |
Driving system |
Chain drive |
Gearbox drive |
|
9 |
Rollers’ materail |
GCr15 |
Cr12 |
|
10 |
Station structure |
Wall panel station |
Forged Iron station |
|
11 |
Punching system |
Yes |
Hydraulic punching station or Punching press |
|
12 |
Cutting system |
Post-cutting |
Post- universal cutting |
|
13 |
Power supply requirement |
380V 50Hz |
Or according to your requirement |
|
14 |
Machine color |
Industrial blue |
Or according to your requirement |
