Items |
Specifications |
Remarks |
|
Material of coil |
Material Thickness |
1.0-1.5 mm galvanized coils |
|
|
Un Coiler |
3 tons hydraulic |
|
Servo feeding |
Motor |
Delta 1.8kw |
|
Punching device |
Punching |
4 sets of punching die |
|
Forming system |
Forming Speed |
About 2-3pieces/min |
|
|
Roller Stations |
About 16 stations |
|
|
Roller Material |
Gcr15 coated with chrome
|
|
|
Maim Motor Power |
7.5kw |
|
|
Motor cutting Power |
5.5kw |
|
Cutting system |
Material Of Cutting |
CR12mov with quench treatment |
|
|
Hardness |
HRC58-62 |
|
|
Tolerance |
+-1.5mm |
|
|
Cutting blades |
1 set |
|
Electrical control system |
Electric Source |
380V, 50HZ,3 phase Also can satisfy Customer’s requirey |
|
|
Control System |
PLC Delta as list in the note |
|
|
Weight |
About 8 tons |
|
|
Way Of Drive |
1.2 inch chain |
|
Machine size |
mm |
10000mm*700mm*1000mm |
