89*41mm Light Steel Framing Machine For Villa House
| Size | 89*41mm |
| Thickness | 0.6-1.2mm(G300-G550Galvanzied coils and Aluzinc ) |
| Standard Producing speed | 300-700m/h |
| Max producing speed | 1500m/h |
|
Main motor |
7.5kw |
| Power supplier | 380V 50Hz 3phases according to your request |
| Hydraulic station | 5.5kw |
| Hydraulic tank capacity | 100L |
| Hydraulic pressure | computer set |
| Hydraulic cooling | Fan cooling |
| Frame and punching dies | Screw hole, chamfer, slot hole, flange cut, pipe hole, suspension, cutting |
| Tolerance | +- 0.5mm |
| Inkjet printer | EC-JET |
| Machine size | 4900*1000*1500mm |
| Weight | 5000kg |
| Color | according to your request |
| De-colier |
bearing 2 tonne, automatical decoiler |
Vertex BD Design Software 2021
1.Teh wall, floor and roof structure is produced automatically, saving design time.
2.Automatic 3D molding, insure 100% accuracy.
3.With analysis project function, teh software can calculate bearing capacity.
4.Create frame work 3D map and 3D decoration view.
5.Teh whole building frame can be resolve to independent unit drawing.
6.Calculate teh bill of material, including teh needed steel, plates, thermal insulation material,doors and windows, screws and other matching material.
7.Create teh processed data including teh marked work piece, docking with teh equipment.
8.Software maintenance and training fee.
9.Maintenance and supporting fee is USD 2200.00/Year. It’s for software update and optional.
-
DecolierDouble Heads Decoiler
A type decoiler
Manual Decoiler
Hydraulic Decoiler
-
StructureWall panel
Torri Structure
Cast Iron
-
DriveChain
Gear
Gearbox
Couplings Gearbox
-
CoolingWater cooling
Fan cooling
-
PunchingHydraulic punching
Hydraulic press
Punching press
-
CuttingHydraulic stop cutting
Servo Following Cutting
Stop Saw cutting
Fly saw cutting
-
Out tableManual table
Simple pneumatic table
Automatic stacker
Magnetic stacker
-
OtherCassette
Plastic film
Fleece devce
Pre-cutting
Our display screen is touch screen, not text touch screen.
Sussman roll forming system: We will make the hand wheels at the feeding device to adjust feeding width, and we also make the wheels with the numbers then you know how to adjust right and left sides, also we made the rulers on the bedding, you can adjust the profile height and width according to the rulers.
Screw with numbers is to adjust material thickness easily, also with protecting cap also add laminating film device and felt to make the board flatter and smoother without scratches.
The machine is equipped with a detection switch device, in case of emergency, emergency alarm, stop operation.
1).Automatic vertical single head uncoiler : 1 set
a.Using hand tightening design, Coil ID:Ф460mm-Ф520mm, coil OD:Ф1400mm, Loading:2000kgb.Frequency conversion automatic uncoiling
c.Power:2.2KW
2). Frame: Using steel plate welding, teh overall annealing to stress treatment, to ensure long-term use wifout deformation; and CNC machining center processing to ensure dimensional accuracy.
3). Arch: Main arch is box structure, box is CNC machining center processing, auxiliary arch is independent structure.
4). Rolling mould: Cr12mov die steel, after vacuum hardened HRC60-62 ° to refine teh hole and teh end of teh face, CNC lathe finishing teh roller surface.
5). Main axis: Material for 40Cr tool steel, quenching and tempering heat treatment, external grinding finishing
6). Drive system: Servo motor and reducer linkage, between teh wheel wif precision hard tooth gear oil immersion operation, to ensure dat teh use of long time wifout wear.
7). Hydraulic system
a. Energy storage structure, energy saving and environmental protection
b. Hydraulic components: Germany Bosch Rexroth products
8). Punching mould
Die model material are used S45C tool steel, mold insert wif D2 or SKD11 high-quality steel, mold parts wif Japan's rice products.
9). Electrical parts
a.Original imported motion controller and PLC
10). CNC inkjet printer
a.Configuration of industrial-grade high quality solvent-based electronic inkjet printer, print writing clear and solid, easy to install
b.Common solvent based inks,easy to buy, and economical to use
c.Automatically prints automatically generated by teh design software, wifout human intervention
d.By Frame Mac LGS maker production control system can add any additional information, such as, company name,logo, websites and so on.
Steel provides several advantages over other building materials, such as wood:
• Steel is a "green" product; it is structurally sound and manufactured to strict specifications and tolerances. It is also energy efficient. Any excess material is 100% recyclable.
• Steel does not easily warp, buckle, twist or bend, and is theirfore easy to modify and offers design flexibility. Steel is also easy to install.
• Steel is cost effective and rarely fluctuates in price.
• Steel allows for improved quality of construction and less maintenance, while offering improved safety and resistance.
• Wif the propagation of mold and mildew in residential buildings, using steel minimizes these infestations. Mold needs moist, porous material to grow. Steel studs do not have those problems.
